MC74VHC157DTR2

MC74VHC157DTR2 解码器、多路复用器、信号开关 TSSOP-16 标记VHC157

逻辑类型Logic Type| 多路复用器 Multiplexer \---|--- 电路数Number of Circuits| 4 x 2:1 输入数Number of Inputs| 1 电源电压VccVoltage - Supply| 8mA，8mA 静态电流IqCurrent - Quiescent Max| 单电源 Single Supply 输出高，低电平电流Current - Output High, Low| 2 V ~ 5.5 V 低逻辑电平Logic Level - Low| The MC74VHC157 is an advanced high--speed CMOS quad 2--channel multiplexer, fabricated with silicon gate CMOS technology. It achieves high--speed operation similar to equivalent Bipolar--Schottky TTL, while maintaining CMOS low--power dissipation. It consists of four 2--input digital multiplexers with common select S and enable E inputs. When E is held High, selection of data is inhibited and all the outputs go Low.The select decoding determines whether the A or B inputs get routed to the corresponding Y outputs.The internal circuit is composed of three stages, including a buffer output which provides high noise immunity and stable output. The inputs tolerate voltages up to 7 V, allowing the interface of 5 V systems to 3 V systems. High Speed: tPD = 4.1 ns Typ at VCC = 5 V Low Power Dissipation: ICC = 4 mA Max at TA = 25°C High Noise Immunity: VNIH = VNIL = 28% VCC Power Down Protection Provided on Inputs Balanced Propagation Delays Designed for 2 V to 5.5 V Operating Range Low Noise: VOLP = 0.8 V Max Pin and Function Compatible with Other Standard Logic Families Latchup Performance Exceeds 300 mA ESD Performance: HBM > 2000 V; Machine Model > 200 V Chip Complexity: 82 FETs 高逻辑电平Logic Level - High| MC74VHC157是一种先进的 - 高速CMOS四-2 通道多路复用器，用硅栅CMOS技术制造。它实现了类似于等效双极-肖特基TTL的高速运转，同时保持CMOS低-功耗。 它由四个有着共同选择（S）和使能（E）输入的2-输入数字多路复用器组成。当E保持高，数据选择被禁止，所有输出变低。选择解码决定是否将A或B输入路由到相应的Y输出。内部电路由三个阶段组成，包括一个缓冲区输出，提供高抗干扰性和稳定的输出。耐输入电压高达7 V，3 V系统允许5 V系统的接口。 高速：TPD= 4.1 ns（典型值），VCC= 5 V 低功耗：ICC= 4 mA（最大），在TA= 25°C时 高抗干扰：VNIH= VNIL=28％VCC 断电保护的输入端 平衡传输延时 设计用于2 V至5.5 V工作范围 低噪声：VOLP= 0.8 V（最大值） 引脚和功能兼容与其他标准逻辑系列 闭锁性能超过300毫安 ESD性能：HBM>2000 V机型号>200 V 芯片的复杂性：82场效应管 传播延迟时间@Vcc，CLMax Propagation Delay @ V, Max CL| Description & Applications| 描述与应用|
