•肖特基势垒二极管(SBD)•超高速开关•小电流整流•IF(AV)=100毫安整改是可能的•最佳高频整流,快速反向恢复•低正向电压VF和良好的整流效率•串联的肖特基二极管
反向电压VrReverse Voltage| 30V \---|--- 平均整流电流IoAVerage Rectified Current| 70mA 最大正向压降VFForward VoltageVf | 550mV/0.55V 最大耗散功率PdPower dissipation| Description & Applications| • Schottky Barrier Diodes SBD • For super high speed switching • For small current rectification • IFAV = 100 mA rectification is possible • Optimum for high frequency rectification because of its short reverse recovery time trr • Low forward voltage VF and good rectification efficiency • Schottky Barrier Diodes in Series 描述与应用| •肖特基势垒(SBD) •超高速开关 •小电流整流 •IF(AV)=100毫安整改是可能的 •最佳高频整流,快速反向恢复 •低正向电压VF和良好的整流效率 •串联的肖特基二极管
