2输入与门
Now you can design fundamental logical circuits using some of "s logic gates! This gate has an operating temperature range of -40 °C to 85 °C. This product comes in rail packaging to keep individual parts separated and protected. This device has a typical operating supply voltage of 2.5|3.3 V. Its minimum operating supply voltage of 2 V, while its maximum is 3.6 V.
电源电压DC 2.30V min
无卤素状态 Halogen Free
输出接口数 1
输出电流 24 mA
电路数 4
逻辑门个数 4
输入数 2
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2V ~ 3.6V
电源电压Max 3.6 V
电源电压Min 2.3 V
安装方式 Surface Mount
引脚数 14
封装 SOIC-14
高度 1.5 mm
封装 SOIC-14
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MC74LCX08DG ON Semiconductor 安森美 | 当前型号 | 当前型号 |
MC74LCX08DR2G 安森美 | 类似代替 | MC74LCX08DG和MC74LCX08DR2G的区别 |
MC74LCX08D 安森美 | 类似代替 | MC74LCX08DG和MC74LCX08D的区别 |
MC74LCX08DR2 安森美 | 类似代替 | MC74LCX08DG和MC74LCX08DR2的区别 |
