MT16JTF25664HZ-1G4G1

MODULE DDR3 SDRAM 2GB 204SODIMM

* DDR3 functionality and operations supported * 240-pin, unbuffered dual in-line memory module UDIMM * Fast data transfer rates: PC3-10600, PC3-8500, or PC3-6400 * 2GB 256 Meg x 64 * VDD = VDDQ = +1.5V ± 075V * VDDSPD = + 3.0V to + 3.6V * Reset pin for improved system stability * Nominal and dynamic on-die termination ODT for data, strobe, and mask signals * Dual rank * 8 internal device banks for concurrent operation * Fixed burst length of 8 BL8 and burst chop of 4 BC4 via the mode register * Adjustable data-output drive strength * Serial presence-detect SPD EEPROM * Gold edge contacts * Pb-free * Addresses are mirrored for second rank * Fly-by topology * Terminated command, address, and control bus
