MLG0603P27NJT000

固定电感器

固定器

立创商城:
27nH ±5% 1.45Ω

得捷:
FIXED IND 27NH 140MA 2.1 OHM SMD

艾睿:
This high frequency chip MLG0603P27NJT000 surface mount inductor from TDK is available in all standard chip sizes in multilayer thick film and thin film deposition and wire wound styles. This SMD inductor has an operating temperature range of -55 °C to 125 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. It has a tolerance of 5%. This product is 0.63 mm long, 0.33 mm tall and 0.33 mm deep. This SMD inductor has a maximum DC current of 140m A with a maximum resistance of 2.1 Ohm. It has an inductance of 27n H. Its test frequency is 500M Hz, while its minimum self-resonant frequency is 2.2G Hz. This device utilizes multi-layer technology.

Verical:
Inductor High Frequency Chip Unshielded Multi-Layer 0.027uH 5% 500MHz 14Q-Factor Ceramic 0.14A 2.1Ohm DCR 0201 T/R

Win Source:
FIXED IND 27NH 140MA 2.1 OHM SMD
