八D型锁存器具有三态输出 Octal D−Type Latch with 3−State Output
D 型透明 1 通道 8:8 IC 三态 20-TSSOP
立创商城:
MC74VHCT373ADTRG
得捷:
IC LATCH TRANSP OCT 2ST 20-TSSOP
艾睿:
This d-type MC74VHCT373ADTRG low-level latch manufactured by ON Semiconductor contains real time information and can be pushed through it once it is enabled. With a 3-state output, this is power management at its best. This latch has a minimum operating temperature of -40 °C and a maximum of 85 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This non-inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 4.5 V, while its maximum is 5.5 V. It has 8 channels per chip.
安富利:
Latch Transparent 3-ST 8-CH D-Type 20-Pin TSSOP T/R
Verical:
Latch Transparent 3-ST 8-CH D-Type Automotive 20-Pin TSSOP T/R
Win Source:
D-Type Transparent Latch 1 Channel 8:8 IC Tri-State 20-TSSOP
无卤素状态 Halogen Free
输出接口数 8
电路数 8
通道数 8
位数 8
输入数 8
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 4.5V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 4.5 V
安装方式 Surface Mount
引脚数 20
封装 TSSOP-20
长度 6.6 mm
宽度 4.5 mm
高度 1.05 mm
封装 TSSOP-20
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MC74VHCT373ADTRG ON Semiconductor 安森美 | 当前型号 | 当前型号 |
74VHCT373AMTCX 安森美 | 完全替代 | MC74VHCT373ADTRG和74VHCT373AMTCX的区别 |
SN74AHCT373PWR 德州仪器 | 类似代替 | MC74VHCT373ADTRG和SN74AHCT373PWR的区别 |
SN74AHCT373PW 德州仪器 | 类似代替 | MC74VHCT373ADTRG和SN74AHCT373PW的区别 |
