Latch Transparent 3-ST 8CH D-Type 20Pin SOP-II T/R
This d-type low-level latch from Semiconductor is a staple for any circuit designer. With a 3-state output, this is power management at its best. This latch has an operating temperature range of -40 °C to 85 °C. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This non-inverting device has a typical operating supply voltage of 2.5|3.3|5 V. Its minimum operating supply voltage of 2 V, while its maximum is 6 V. It has 8 channels per chip.
电源电压DC 2.00V min
输出接口数 8
输出电流 7.8 mA
电路数 8
通道数 8
位数 8
输入数 8
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2V ~ 6V
电源电压Max 6 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 20
封装 SOP-20
长度 12.6 mm
宽度 5.3 mm
高度 1.8 mm
封装 SOP-20
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
MM74HC373SJX Fairchild 飞兆/仙童 | 当前型号 | 当前型号 |
MM74HC373SJ 安森美 | 类似代替 | MM74HC373SJX和MM74HC373SJ的区别 |
