4位D触发器三态输出
"s flip flop device will allow you to easily build and test a circuit based on the state information provided. It has a single-ended output signal. With a 3-state output, this is power management at its best. This flip flop has an operating temperature range of -55 °C to 125 °C. This product comes in rail packaging to keep individual parts separated and protected. This non-inverting device has a typical operating supply voltage of 3.3|5|9|12|15 V. Its minimum operating supply voltage of 3 V, while its maximum is 18 V. It has 4 channels per chip.
频率 6 MHz
电源电压DC 3.00V min
输出接口数 4
输出电流 8.8 mA
电路数 4
时钟频率 12 MHz
位数 4
极性 Non-Inverting
逻辑门个数 4
输入电容 5 pF
输入数 4
工作温度Max 125 ℃
工作温度Min -55 ℃
电源电压 3V ~ 18V
电源电压Max 18 V
电源电压Min 3 V
安装方式 Through Hole
引脚数 16
封装 DIP-16
封装 DIP-16
工作温度 -55℃ ~ 125℃ TA
产品生命周期 Unknown
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MC14076BCPG ON Semiconductor 安森美 | 当前型号 | 当前型号 |
CD4076BE 德州仪器 | 功能相似 | MC14076BCPG和CD4076BE的区别 |
MC14076BDR2G 安森美 | 功能相似 | MC14076BCPG和MC14076BDR2G的区别 |
MC14076BDG 安森美 | 功能相似 | MC14076BCPG和MC14076BDG的区别 |
