八路D触发器与时钟使能 Octal D Flip−Flop with Clock Enable
brings you their latest flip flop device, a simple yet effective method for storing your circuit"s state information. It has a single-ended output signal. This flip flop has an operating temperature range of -40 °C to 85 °C. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. It has 8 channels per chip. This non-inverting device has a typical operating supply voltage of 5 V. Its minimum operating supply voltage of 2 V, while its maximum is 6 V.
电源电压DC 6.00V max
无卤素状态 Halogen Free
输出接口数 8
电路数 8
时钟频率 140 MHz
位数 8
极性 Non-Inverting
输入电容 4.5 pF
输入数 8
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2V ~ 6V
电源电压Max 6 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 20
封装 SOIC-20
封装 SOIC-20
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
MC74AC377DWR2G ON Semiconductor 安森美 | 当前型号 | 当前型号 |
MC74AC377DWR2 安森美 | 完全替代 | MC74AC377DWR2G和MC74AC377DWR2的区别 |
