MC100LVELT23 系列 3.8 V 双 差分 LVPECL/LVDS转LVTTL 转换器
Description
The MC100LVELT23 is a dual differential LVPECL/LVDS to LVTTL translator. Because LVPECL Positive ECL or LVDS levels are used only +3.3 V and ground are required. The small outline 8-lead package and the dual gate design of the LVELT23 makes it ideal for applications which require the translation of a clock and a data signal.
The LVELT23 is available in only the ECL 100K standard. Since there are no LVPECL outputs or an external VBB reference, the LVELT23 does not require both ECL standard versions. The LVPECL inputs are differential. Therefore, the MC100LVELT23 can accept any standard differential LVPECL input referenced from a VCC of +3.3 V.
Features
• 2.0 ns Typical Propagation Delay
• Maximum Frequency > 180 MHz
• Differential LVPECL Inputs
• PECL Mode Operating Range:VCC = 3.0 V to 3.8 V with GND = 0 V
• 24 mA LVTTL Outputs
• Flow Through Pinouts
• Internal Pulldown and Pullup Resistors
• These Devices are Pb-Free, Halogen Free and are RoHS Compliant
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MC100LVELT23DR2G ON Semiconductor 安森美 | 当前型号 | 当前型号 |
MC100LVELT23DG 安森美 | 完全替代 | MC100LVELT23DR2G和MC100LVELT23DG的区别 |
MC100LVELT23DTG 安森美 | 完全替代 | MC100LVELT23DR2G和MC100LVELT23DTG的区别 |
MC100LVELT23MNRG 安森美 | 完全替代 | MC100LVELT23DR2G和MC100LVELT23MNRG的区别 |
