MC74AC373DTR2概述

八路透明锁存器具有三态输出 Octal Transparent Latch with 3−State Outputs

Octal Transparent Latch with 3 State Outputs

The MC74AC373/74ACT373 consists of eight latches with 3−state outputs for bus organized system applications. The flip−flops appear transparent to the data when Latch Enable LE is HIGH. When LE is LOW, the data that meets the setup time is latched. Data appears on the bus when the Output Enable OE is LOW. When OEis HIGH, the bus output is in the high impedance state.

Features

•Eight Latches in a Single Package

•3−State Outputs for Bus Interfacing

•Outputs Source/Sink 24 mA

•′ACT373 Has TTL Compatible Inputs

•Pb−Free Packages are Available

MC74AC373DTR2中文资料参数规格
技术参数

工作温度Max 85 ℃

工作温度Min -40 ℃

电源电压 2V ~ 6V

封装参数

安装方式 Surface Mount

引脚数 20

封装 TSSOP-20

外形尺寸

封装 TSSOP-20

物理参数

工作温度 -40℃ ~ 85℃ TA

其他

产品生命周期 Unknown

包装方式 Tape & Reel TR

符合标准

RoHS标准 Non-Compliant

含铅标准 Contains Lead

海关信息

ECCN代码 EAR99

数据手册

MC74AC373DTR2引脚图与封装图
MC74AC373DTR2引脚图
MC74AC373DTR2封装图
MC74AC373DTR2封装焊盘图
