VISHAY MAL215376101E3 铝电解电容, 表面贴装, 153 CRV系列, 100 µF, 25 V, Radial Can - SMD, 8 mm, 0.5 ohm
The is a SMD chip long life polarized Aluminium Electrolytic Capacitor feature non-solid electrolyte and self healing property. The 153 CRV series SMD-version is available with base plate, vertical construction requiring minimum board space, lead Pb-free reflow solderable. In general, aluminium capacitor is the most suitable capacitor for addressing requirements such as low and high frequency filtering and energy storage, which demand high capacitance values and power ratings. The device offers high CU/unit cost ratios, is small compared with other technologies and is relatively insensitive to voltage spikes. An electrochemically etched aluminium anode foil forms the first plate of the capacitor. An oxide layer on the etched aluminium foil that forms the dielectric. A paper spacer impregnated with fluid electrolyte in contact with the oxide layer to form the second plate of the capacitor. A second foil that forms the other contact with the fluid electrolyte.
额定电压DC 25.0 V
电容 100 µF
等效串联电阻ESR 0.5 Ω
容差 ±20 %
纹波电流 180 mA
工作温度Max 105 ℃
工作温度Min -55 ℃
额定电压 25 V
安装方式 Surface Mount
引脚数 2
封装 SMD
高度 10 mm
直径 8.00 mm
封装 SMD
介质材料 Aluminum Electrolytic
工作温度 -55℃ ~ 105℃
包装方式 Cut Tape CT
寿命(小时) 2000h @105℃
制造应用 电源管理, Portable Devices, Automotive, 工业, 通信与网络, 便携式器材, 车用, Power Management, Communications & Networking, Industrial
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MAL215376101E3 Vishay Semiconductor 威世 | 当前型号 | 当前型号 |
MAL214097602E3 威世 | 类似代替 | MAL215376101E3和MAL214097602E3的区别 |
MCEEL25V107M8X10.5 Multicomp | 功能相似 | MAL215376101E3和MCEEL25V107M8X10.5的区别 |
