Conn Miniature Cylindrical PIN 8POS Solder ST Box Mount 8 Terminal 1Port
Conn Miniature Cylindrical PIN 8 POS Solder ST Box Mount 8 Terminal 1 Port
艾睿:
Conn Circular PIN 8 POS Solder ST Box Mount 8 Terminal 1 Port
Chip1Stop:
Conn Miniature Cylindrical PIN 8 POS Solder ST Box Mount 8 Terminal 1 Port
Verical:
Conn Circular PIN 8 POS Solder ST Box Mount 8 Terminal 1 Port
Newark:
# AMPHENOL INDUSTRIAL MS3112E12-8P Circular Connector, MIL-DTL-26482 Series I, Box Mount Receptacle, 8 Contacts, Solder Pin, Bayonet
MASTER:
Conn Miniature Cylindrical PIN 8 POS Solder ST Box Mount 8 Terminal 1 Port
Powell:
Circular MIL Spec Connector 8P #20 PIN CONTACTS
Online Components:
Conn Miniature Cylindrical PIN 8 POS Solder ST Box Mount 8 Terminal 1 Port
Electro Sonic:
Conn Miniature Cylindrical PIN 8 POS Solder ST Box Mount 8 Terminal 1 Port
触点数 8
极性 Male
触点电镀 Gold
额定电流 5.00 A
绝缘电阻 5000 MΩ
针脚数 8
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压Max 600 VAC
额定电压 600 VAC
安装方式 Solder, Box
长度 24.33 mm
宽度 26.18 mm
高度 26.18 mm
触点材质 Copper Alloy
工作温度 -55℃ ~ 125℃
外壳材质 Aluminum
产品生命周期 Active
RoHS标准 Non-Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
军工级 Yes
HTS代码 8536694020
