MAX6070BAUT33+T

电压基准, 串联 - 固定, 3.3V, 0.08％Ref, ±2ppm/°C, SOT-23-6

* High ±0.04% Initial Accuracy * Low 1.5ppm/°C typ, 6ppm/°C max Temperature Drift * Low 4.8µVP-P Noise 0.1Hz to 10Hz at 2.5V * Low 150µA Supply Current * 10mA Source/Sink Load Current * Noise Filter Option * Low 200mV Dropout Voltage * High 85dB Ripple Rejection * Small 6-Pin SOT23 Package * Voltage Output Options: 1.25V, 1.8V, 2.048V, 2.5V, 3.0V, 3.3V, 4.096V, and 5.0V

得捷:
IC VREF SERIES 0.08% SOT23-6

立创商城:
MAX6070BAUT33+T

e络盟:
电压基准, 串联 - 固定, 3.3V, 0.08％Ref, ±2ppm/°C, SOT-23-6

安富利:
V-Ref Precision 3.3V 10mA 6-Pin SOT-23
