MAX6318LHUK46CY+T

监控器, 高/低电平有效, 推挽, 1-5.5V电源, 4.63 V阈值, 200 ms延迟, SOT-23-5

The from Products is an automotive grade microprocessor µP supervisory circuit with watchdog and manual reset in 5 pin SOT23 package. This µP monitors power supplies and microprocessor activity in digital systems. It offers several combinations of push/pull, open-drain and bidirectional such as Motorola 68HC11 reset outputs along with watchdog and manual reset features. It is ideally used at portable computers, controllers, computers, intelligent instruments, portable/battery-powered equipment and embedded control systems.

.

Supply voltage range is 1V to 5.5V

.

Operating temperature range from -40°C to +125°C

.

Reset output stages active low push/pull and active high push/pull

.

Watchdog input, integrated features increase robustness

.

Guaranteed reset valid to VCC = 1V, immune to short-negative VCC transients

.

4.63V reset threshold

.

140ms minimum reset time

.

1.6s typical watchdog time out

.

Saves board space, no external components
