0603 外壳 51 Ohms 5% 容差 200 PPM
罗姆 贴片 0603 51Ω ±5%
立创商城:
51Ω ±5% 100mW
得捷:
RES SMD 51 OHM 5% 1/10W 0603
艾睿:
Res Thick Film 0603 51 Ohm 5% 0.1W1/10W ±200ppm/°C Epoxy Resin Pad SMD Automotive T/R
安富利:
Chip resistors are highly reliable due to metal-glaze resistive element. They are long-seller in the market for needs from consumer electronics to industrial/automotive. The packages are available from the ultra-compact size best matching mobile communication appliances and portable equipment.
富昌:
表面贴装 厚膜 贴片电阻 0603 外壳 51 Ohms 5% 容差 200 PPM
Chip1Stop:
Res Thick Film 1.6 x 0.8 mm 51 Ohm 5% 0.1W1/10W 200ppm/ C Molded SMD Paper T/R
Verical:
Res Thick Film 0603 51 Ohm 5% 0.1W1/10W ±200ppm/C Pad SMD Automotive T/R
额定电压DC 50.0 V
容差 ±5 %
额定功率 0.1 W
产品系列 MCR
电阻 51 Ω
阻值偏差 ±5 %
工作温度Max 155 ℃
工作温度Min -55 ℃
安装方式 Surface Mount
封装公制 1608
封装 0603
长度 1.6 mm
宽度 0.8 mm
高度 0.45 mm
封装公制 1608
封装 0603
工作温度 -55℃ ~ 155℃
温度系数 ±200 ppm/℃
产品生命周期 Discontinued at Digi-Key
包装方式 Tape & Reel TR
RoHS标准
含铅标准 Lead Free
香港进出口证 NLR
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MCR03EZPJ510 ROHM Semiconductor 罗姆半导体 | 当前型号 | 当前型号 |
RK73B1JLTD510J KOA Speer | 类似代替 | MCR03EZPJ510和RK73B1JLTD510J的区别 |
CRCW060351R0JNEA 威世 | 功能相似 | MCR03EZPJ510和CRCW060351R0JNEA的区别 |
CR0603-JW-510GLF 伯恩斯 | 功能相似 | MCR03EZPJ510和CR0603-JW-510GLF的区别 |
