MPXH6400AC6T1

NXP  MPXH6400AC6T1  压力传感器, 绝对, 12.1 mV/kPa, 20 kPa, 400 kPa, 4.64 V, 5.36 V

The is an Integrated Pressure Sensor with bipolar op-amp circuitry and thin film resistor networks to provide a high output signal and temperature compensation. The small form factor and high reliability of on-chip integration make this pressure sensor a logical and economical choice for the system designer. The piezoresistive transducer is a state-of-the-art, monolithic, signal conditioned, silicon pressure sensor. This sensor combines advanced micromachining techniques, thin film metallization and bipolar semiconductor processing to provide an accurate, high level analogue output signal that is proportional to applied pressure.

.

1.5% Maximum error over 0 to 85°C

.

Improved accuracy at high temperature

.

Fully calibrated and compensated

.

Ideally suited for microprocessor or microcontroller-based systems
