MCP1725-5002E/MC

MICROCHIP  MCP1725-5002E/MC  固定电压稳压器, LDO, 2.3V至6V, 210mV压差, 5V输出, 500mA输出, DFN-8

MCP1725 低压降电压稳压器

得捷:
IC REG LINEAR 5V 500MA 8DFN

立创商城:
MCP1725-5002E/MC

欧时:
Microchip MCP1725-5002E/MC LDO 稳压器, 5 V输出, 500mA最大输出, 2%精确度, 2.3 → 6 V输入, 8引脚

贸泽:
LDO Voltage Regulators 500mA CMOS LDO Vout=5.0V

e络盟:
MICROCHIP  MCP1725-5002E/MC  固定电压稳压器, LDO, 2.3V至6V, 210mV压差, 5V输出, 500mA输出, DFN-8

艾睿:
Use the LDO MCP1725-5002E/MC linear regulator from Microchip Technology to maintain a constant output voltage. It has an overall accuracy of ±2 %. Its typical dropout voltage at current is 0.21@500mA V. This voltage regulation device&s;s single output can produce a current up to 0.5Min A. Use this part at voltages between 2.3 V and 6 V. With a fixed output that has a voltage of 5 V, this is power management at its best. By operating at a load regulation of 0.5%Typ and line regulation of 0.05%/VTyp you can provide a constant voltage at your output. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive. The maximum dropout voltage is 0.35@500mA V.

Allied Electronics:
MCP1725-5002E/MC, LDOVoltage Regulator, 500mA, 5V 2%, 2.3 to 6Vin, 8-Pin DFN

Chip1Stop:
LDO Regulator Pos 5V 0.5A Automotive 8-Pin DFN EP

Newark:
# MICROCHIP  MCP1725-5002E/MC  Fixed LDO Voltage Regulator, 2.3V to 6V, 210mV Dropout, 5Vout, 500mAout, DFN-8
