MAX1771CSA

12V或可调，高效率，低IQ ，升压型DC- DC控制器 12V or Adjustable, High-Efficiency, Low IQ, Step-Up DC-DC Controller

General Description

The MAX1771 step-up switching controller provides 90% efficiency over a 30mA to 2A load. A unique cur rent-limited pulse-frequency-modulation PFM control scheme gives this device the benefits of pulse-width modulation PWM converters high efficiency at heavy loads, while using less than 110µA of supply current vs. 2mA to 10mA for PWM converters.

Features

♦ 90% Efficiency for 30mA to 2A Load Currents

♦ Up to 24W Output Power

♦ 110µA Max Supply Current

♦ 5µA Max Shutdown Current

♦ 2V to 16.5V Input Range

♦ Preset 12V or Adjustable Output Voltage

♦ Current-Limited PFM Control Scheme

♦ Up to 300kHz Switching Frequency

♦ Evaluation Kit Available
