MAX16828ASA+T

LED照明驱动器 100/200mA Adj Lnear HB w/PWM Dimming

LED 驱动器 IC 1 输出 线性 - PWM 调光 200mA 8-SOIC-EP

得捷:
IC LED DRVR LIN PWM 200MA 8SOIC

贸泽:
LED照明驱动器 100/200mA Adj Lnear HB w/PWM Dimming

安富利:
The MAX16815/MAX16828 current regulators operate from a 6.5V to 40V input voltage range and deliver up to 100mA MAX16815 or 200mA MAX16828 to high-brightness LED HB LED loads. The output current is adjusted by using an external current sense resistor in series with the LEDs. The MAX16815/MAX16828"s dimming input allows wide-range "pulsed" PWM operation. An on-board pass element minimizes external components while providing ±3.5% output-current accuracy.The MAX16815/MAX16828 are available in a thermally enhanced, 3mm x 3mm, 6-pin TDFN package with exposed pad and in an 8-pin SO package with exposed pad; they are specified over the automotive -40°C to +125°C temperature range.

Win Source:
LED Driver IC 1 Output Linear PWM Dimming 200mA 8-SOIC Exposed Pad
