MINT3110A1708K01

SL POWER CONDOR 110W 3输出 嵌入式开关模式电源（SMPS）, 15 V, -15 V, 5 V, 1 A, 14 A, 4.5 A

A superior performance 425 watts AC to DC power supply designed for test and measurement and industrial applications. Feature rich and highly efficient TU425 product family with active current share for redundant applications can easily fit in 1U chassis and provides 300 watts for convection or 425 watts with moving air. Input and output monitoring alarms plus isolated 12 V/1 A fan output and 5 V/2 A standby voltage are among other standard offering of TU425 family. All models are CE marked to low voltage directive and approved to ITE standards of IEC/UL/EN60950 and CSA C22.2, 2nd edition.

.

*

Features:

**

* 3.3" × 6.2" × 1.62" Package

* Up to 425 W of Air-Cooled Power, 300 W Convection

* Universal Input 90-264 Vac Input Range

* 5 V at 2 A Isolated Standby Output

* Isolated 12 V Fan Output

* Inhibit, Power Fail, DC OK Signals, Remote Sense

* Approved to CSA/EN/IEC/UL60950-1, 2nd Edition

* Compliant to High Levels of EMC per EN61000-4

* Meets Class B Conducted EMI with 6 db Margin,

* Class A Radiated EMI with 3 db Margin

* Efficiency 90% Typical

* 3 Year Warranty
