M93C46-WMN6

16Kbit的， 8Kbit ， 4k位， 2Kbit和的1K位（ 8位或16位宽） MICROWIRE串行EEPROM的访问 16Kbit, 8Kbit, 4Kbit, 2Kbit and 1Kbit 8-bit or 16-bit wide MICROWIRE Serial Access EEPROM

Description

The M93C86, M93C76, M93C66, M93C56 and M93C46 are electrically erasable programmable memory EEPROM devices. They are accessed through a Serial Data input D and Serial Data output Q using the MICROWIRE bus protocol

Features

● Industry standard MICROWIRE bus

● Single supply voltage:

   – 4.5 V to 5.5 V for M93Cx6

   – 2.5 V to 5.5 V for M93Cx6-W

   – 1.8 V to 5.5 V for M93Cx6-R

● Dual organization: by word x16 or byte x8

● Programming instructions that work on: byte, word or entire memory

● Self-timed programming cycle with auto erase: 5 ms

● READY/BUSY signal during programming

● 2 MHz clock rate

● Sequential read operation

● Enhanced ESD/latch-up behavior

● More than 1 million write cycles

● More than 40 year data retention

● Packages

   – ECOPACK® RoHS compliant
