MCIMX355AJQ5C概述

i.MX35 32Bit MPU, ARM1136JF-S core, 532MHz, MAPBGA 400

The i.MX35 Auto Application Processor family is designed for automotive infotainment and navigation applications. These processors are AECQ100 Grade 3 qualified and rated for ambient operating temperatures up to 85 °C. Based on an ARM11 microprocessor core running at up to 532 MHz, the device offers the following features and optimized system cost for the target applications.

• Audio connectivity and telematics:

— Compressed audio playback from storage devices CD, USB, HDD or SD card

— PlayFromDevice 1-wire and 2-wire support for portable media players

— iPod/iPhone control and playback

— High-speed CD ripping to USB,SD/MMC or HDD for virtual CD changer

— Audio processing for hands-free telephony: Bluetooth, AEC/NS, and microphone beam forming

— Speech recognition

• A/V connectivity and navigation:

— Includes audio connectivity and telematics features

— Map display and route calculation

— QVGA video decode, WVGA video display

— Sophisticated graphical user interface

MCIMX355AJQ5C中文资料参数规格
技术参数

电源电压DC 1.33V min

无卤素状态 Halogen Free

时钟频率 532 MHz

工作温度Max 85 ℃

工作温度Min 40 ℃

封装参数

安装方式 Surface Mount

引脚数 400

封装 LFBGA-400

外形尺寸

封装 LFBGA-400

物理参数

工作温度 -40℃ ~ 85℃ TA

其他

产品生命周期 Active

包装方式 Tray

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

REACH SVHC标准 No SVHC

海关信息

香港进出口证 NLR

数据手册

在线购买MCIMX355AJQ5C
型号: MCIMX355AJQ5C
制造商: Freescale 飞思卡尔
描述:i.MX35 32Bit MPU, ARM1136JF-S core, 532MHz, MAPBGA 400
