Pressure Sensor 0.6V to 3V 0kPa to 3.92kPa Gage 8Pin SOP Tray
Integrated Silicon Pressure Sensor, On-Chip Signal Conditioned, Temperature Compensated and
Calibrated
The MP3V5004G series piezoresistive transducer is a state-of-the-art monolithic silicon pressure sensor designed for a wide range of applications, but particularly those employing a microcontroller or microprocessor with A/D inputs. This sensor combines a highly sensitive
implanted strain gauge with advanced micromachining techniques, thin-film metallization, and bipolar processing to provide an accurate, high level analog output signal that is proportional to the applied pressure.
Features
• Temperature Compensated from 10°C to 60°C
• Available in Gauge Surface Mount SMT Configuration
• Durable Thermoplastic PPS Package
Typical Applications
• Washing Machine Water Level
• Ideally Suited for Microprocessor or Microcontroller-Based Systems
