MAX4652EUE+T

Low-Voltage, 4Ω, Quad, SPST, CMOS Analog Switches

电路 IC 开关 1：1 4 欧姆 16-TSSOP

得捷:
IC SWITCH QUAD SPST 16TSSOP

立创商城:
MAX4652EUE+T

安富利:
The MAX4651/MAX4652/MAX4653 quad analog switches feature 4Ω max on-resistance RON when operating from a single +5V supply. RON is matched between switches to 0.2Ω max and is flat 0.8Ω max over the specified signal range. Each switch can handle rail-to-rail analog signals. Off-leakage current is 0.1nA at +25°C. These switches are ideal in low-distortion applications and are the preferred solution over mechanical relays in automated test equipment or applications where current switching is required. They have low power requirements, require less board space, and are more reliable than mechanical relays.The MAX4651/MAX4652/MAX4653 operate from a single +1.8V to +5.5V supply, making them ideal for use in battery-powered applications.The MAX4651 has four normally closed NC switches, the MAX4652 has four normally open NO switches, and the MAX4653 has two NO and two NC switches. These devices are available in 16-pin QFN, TSSOP and SO packages, as well as 20-pin QFN package.

Win Source:
IC SWITCH QUAD SPST 16TSSOP
