MAX3483CSA+

RS-485 Single Transmitters/Receivers, 3.3V, Maxim Integrated### RS-485 线路驱动器和接收器

RS-485 Single Transmitters/Receivers, 3.3V,

### RS-485 线路驱动器和接收器

得捷:
IC TRANSCEIVER HALF 1/1 8SOIC

欧时:
### RS-485 Single Transmitters/Receivers, 3.3V, Maxim Integrated### RS-485 线路驱动器和接收器

e络盟:
The MAX3483CSA+ is a slew-rate-limited Low-power Transceiver for RS-485/RS-422 communication. Each part contains one driver and one receiver. The MAX3483 feature slew-rate-limited drivers that minimize EMI and reduce reflections caused by improperly terminated cables, allowing error-free data transmission at data rates up to 250kbps. Drivers are short-circuit current limited and are protected against excessive power dissipation by thermal shutdown circuitry that places the driver outputs into a high-impedance state. The receiver input has a fail-safe feature that guarantees a logic-high output if both inputs are open circuit.

Chip1Stop:
Single Transmitter/Receiver RS-422/RS-485 8-Pin SOIC N

TME:
Interface; transceiver; RS422,RS485,half duplex; 250kbps; SO8

Win Source:
1/1 Transceiver Half RS422, RS485 8-SOIC

DeviceMart:
IC TXRX RS485/422 250KBPS 8-SOIC
