数模转换器- DAC 8-Bit 2Ch Precision DAC
Bit Digital to Analog Converter
得捷:
CMOS, DUAL, BUFFERED, 8-BIT MULT
贸泽:
数模转换器- DAC 8-Bit 2Ch Precision DAC
安富利:
The MX7528/MX7628 contains two 8-bit multiplying digital-to-analog converters DACs. Separate on-chip latches hold the input data for each DAC to allow easy interface to microprocessors. The data load operation is similar to a static RAM write cycle. Data is loaded using only active-low CS, active-low WR, and DAC Select active-low DAC A /DAC B inputs.Each DAC has a separate reference input and internal feedback resistor which allow fully independent operation while maintaining excellent DAC-to-DAC matching. The MX7528 operates from a single +5 to +15V power supply whereas the MX7628 operates from +12V to +15V. The MX7528 has TTL compatible inputs at +5V supply only and the MX7628 has TTL compatible inputs from +12V to +15V supplies. The MX7528/MX7628 is supplied in 20-lead narrow DIP and Small Outline Packages.
Chip1Stop:
DAC 2-CH R-2R 8-bit 20-Pin SOIC W T/R
Win Source:
IC DAC 8BIT DL MULT 20-SOIC
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MX7628KCWP+T Maxim Integrated 美信 | 当前型号 | 当前型号 |
MX7628KCWP+ 美信 | 完全替代 | MX7628KCWP+T和MX7628KCWP+的区别 |
TLC7528CDW 德州仪器 | 类似代替 | MX7628KCWP+T和TLC7528CDW的区别 |
TLC7528CDWR 德州仪器 | 类似代替 | MX7628KCWP+T和TLC7528CDWR的区别 |
