MAX5150BEPE+

DAC 2CH R-2R 13Bit 16Pin PDIP N

13 Bit Digital to Analog Converter 2 16-PDIP

得捷:
IC DAC 13BIT V-OUT 16DIP

安富利:
The MAX5150/MAX5151 low-power, serial, voltage-output, dual 13-bit digital-to-analog converters DACs consume only 500µA from a single +5V MAX5150 or +3V MAX5151 supply. These devices feature Rail-to-Rail output swing and are available in a space-saving 16-pin QSOP package. To maximize the dynamic range, the DAC output amplifiers are configured with an internal gain of +2.The 3-wire serial interface is SPI™/QSPI™ and MICROWIRE™ compatible. Each DAC has a double-buffered input organized as an input register followed by a DAC register, which allows the input and DAC registers to be updated independently or simultaneously with a 16-bit serial word. Additional features include programmable shutdown 2µA, hardware-shutdown lockout, a separate reference voltage input for each DAC that accepts AC and DC signals, and an active-low clear input CL that resets all registers and DACs to zero. These devices provide a programmable logic pin for added functionality, and a serial-data output pin for daisy-chaining.
