MX7575JN+

ADC, Successive Approximation, 8Bit, 1 Func, 1Channel, Parallel, 8Bits Access, CMOS, PDIP18, PLASTIC, DIP-18

8 Bit Analog to Digital Converter 1 Input 1 SAR 18-PDIP

得捷:
IC ADC 8BIT MPU COMP 18-DIP

安富利:
Maxim"s MX7575/MX7576 are high-speed 5µs/10µs, microprocessor µP compatible, 8-bit analog-to-digital converters ADCs. The MX7575 provides an on-chip track/hold function that allows full-scale signals up to 50kHz 386mV/µs slew rate to be acquired and digitized accurately. Both ADCs use a successive-approximation technique to achieve their fast conversions and low power dissipation. The MX7575/MX7576 operate with a +5V supply and a 1.23V external reference. They accept input voltages ranging from 0V to 2VREF.The MX7575/MX7576 are easily interfaced to all popular 8-bit µPs through standard CS and RD control signals. These signals control conversion start and data access. A BUSY signal indicates the beginning and end of a conversion. Since all the data outputs are latched and three-state buffered, the MX7575/MX7576 can be directly tied to a µP data bus or system l/O port.Maxim also makes the MAX165, a plug-in replacement for the MX7575 with an internal 1.23V reference. For applications that require a differential analog input and an internal reference, the MAX166 is recommended.
