MAX1296BCEG

420ksps ， + 5V ， 6 / 2通道，12位ADC，带有+ 2.5V电压基准及并行接口 420ksps, +5V, 6-/2-Channel, 12-Bit ADCs with +2.5V Reference and Parallel Interface

* 12-Bit Resolution, ±0.5 LSB Linearity * Single +5V Operation * Internal +2.5V Reference * Software-Configurable Analog Input Multiplexer * 6-Channel Single-Ended/3-Channel Pseudo-Differential MAX1294 * 2-Channel Single-Ended/1-Channel Pseudo-Differential MAX1296 * Software-Configurable Unipolar/Bipolar Analog Inputs * Low Current * 2.8mA 420ksps * 1.0mA 100ksps * 400µA 10ksps * 2µA Shutdown * Internal 6MHz Full-Power Bandwidth Track/Hold * Parallel 12-Bit Interface * Small Footprint * 28-Pin QSOP MAX1294 * 24-Pin QSOP MAX1296
