XP POWER MTC15028S15 Isolated Board Mount DC-DC Converter, Vetronic & Avionic, Fixed, Adjustable, 1 Output, 10V, 40V
MTC Series, 5-30 Watts. 10 50 VDC Input Range. Designed for Vetronic & Avionic Use. Single & Dual Output Versions. -55 °C Operation Available. MIL STD 461 and DEF STAN 59 411. MIL STD 1275 and DEF STAN 61 5. 3 Year Warranty.
得捷:
DC DC CONVERTER 15V 150W
Allied Electronics:
Power Supply; 150W mil-spec DC-DC converter single output
Newark:
# XP POWER MTC15028S15 Isolated Board Mount DC/DC Converter, Vetronic & Avionic, Fixed, Adjustable, 1 Output, 10 V, 40 V
额定功率 150 W
输出接口数 1
输出电压 15 VDC
输出功率 150 W
隔离电压 1.5 kV
输入电压Max 40 V
输入电压Min 10 V
输入电压DC Max 40 V
输入电压DC Min 10 v
输出电流Max 10 A
输出功率Max 150 W
输入电压 10VDC ~ 40VDC
安装方式 Through Hole
封装 DIP-12
宽度 57.9 mm
高度 12.7 mm
封装 DIP-12
工作温度 -40℃ ~ 100℃
产品生命周期 Active
包装方式 Box
制造应用 ITE（商业）
RoHS标准 RoHS Compliant
含铅标准 Lead Free
军工级 Yes
