MSA-0636-BLKG

RF Amp Chip Single GP 5GHz 3.9V 4Pin Case 36 Micro-X Bulk

Description

The MSA-0636 is a high performance silicon bipolar Monolithic Microwave Integrated Circuit MMIC housed in a cost effective, microstrip package. This MMIC is designed for use as a general purpose 50Ω gain block. Typical applications include narrow and broad band IF and RF amplifiers in commercial and industrial applications.

Features

• Cascadable 50Ω Gain Block

• Low Operating Voltage: 3.5 V Typical Vd

• 3 dB Bandwidth: DC to 0.9 GHz

• High Gain: 19.0 dB Typical at 0.5 GHz

• Low Noise Figure: 2.8 dB Typical at 0.5 GHz

• Cost Effective Ceramic Microstrip Package
