1A 至 1.5A,Vishay Semiconductor来自 Vishay Semiconductor 的一系列肖特基整流器。 这些二极管具有极低的正向电压降和非常快的切换作用。 肖特基二极管的反向恢复时间非常短且适用于需要快速切换和低功耗的应用。### 肖特基整流器,Vishay Semiconductor
The is a surface-mount Schottky Barrier Rectifier with solderable matte tin-plated terminals. It is suitable for use in low voltage high frequency inverters, free-wheeling, DC/DC converters and polarity protection applications.
针脚数 2
正向电压 0.4 V
热阻 40℃/W RθJC
正向电流 1 A
最大正向浪涌电流(Ifsm) 25 A
正向电压Max 500 mV
正向电流Max 1 A
工作温度Max 150 ℃
工作温度Min -55 ℃
工作结温Max 150 ℃
安装方式 Surface Mount
引脚数 2
封装 MicroSMP
长度 2.3 mm
宽度 1.4 mm
高度 0.73 mm
封装 MicroSMP
工作温度 -55℃ ~ 150℃
产品生命周期 Active
包装方式 Cut Tape CT
制造应用 Power Management, Automotive, Industrial
RoHS标准 RoHS Compliant
含铅标准 Lead Free
