LPC2388 Microcontroller Evaluation Board 12MHz/72MHz CPU 98KB RAM 512KB Flash Win 2000/Win Vista/Win XP
is a Keil MCB2300 evaluation board which introduces to the NXP LPC2380 ARM family and allows to create and test working programs for this advanced architecture. The prototyping area provides blocks for adding components and connecting the address, data, and I/O ports. The LPC2388 microcontroller provided with the MCB2300 board is a high end LPC23xx device with advanced ADC, DAC and USB capabilities. A 12MHz crystal provides the clock signal for the CPU. The JTAG interface connector provides debugging and emulator support for the NXP LPC23xx device. The JTAG interface allows application debugging and programming of on chip and off chip flash devices. Board connects the on chip serial UART to the MAX563, which converts the logic signals to RS232 voltage levels.
- .
- USB 2.0 full speed interface supporting USB Device and USB OTG/Host
- .
- Dual serial ports
- .
- Dual CAN ports
- .
- 100/10M ethernet port
- .
- LCD display
- .
- LF amplifier
- .
- Analog voltage control for ADC input
- .
- JTAG download and debug
