NXP MPX2202AP 芯片, 压力传感器, 0至200KPA, SIP-4
Overview
The MPXx2202 family MPX2202 series, MPXV2202G series, MPXM2202 series of pressure sensors provides silicon piezoresistive devices for medical and industrial applications.
* Offers a highly accurate and linear voltage output directly proportional to the applied pressure.
* Includes a single monolithic silicon diaphragm with the strain gauge and a thin-film resistor network integrated on-chip
* Delivers a laser-trimmed chip for precise span, offset calibration and temperature compensation
MoreLess
## Features
* Temperature compensated over 0° to +85°C
* Available in easy-to-use tape-in-reel and chip carrier package options
* Available in absolute, differential and gauge configurations
* Ratiometric to supply voltage
* Gauge-ported and non-ported options
## Features
电源电压DC 10.0V min
无卤素状态 Not Halogen Free
输出电压 0V ~ 0.04V
供电电流 6.00 mA
针脚数 4
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 10 V
电源电压Max 16 V
电源电压Min 10 V
安装方式 Through Hole
引脚数 4
封装 SIP-01
封装 SIP-01
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Each
RoHS标准
含铅标准 Contains Lead
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MPX2202AP NXP 恩智浦 | 当前型号 | 当前型号 |
