MICROCHIP MCP131T-195I/TT 芯片, 电压监控器, 1.95V, 低有效, SOT-23B
MCP131 微控制器监控和重置电路
### 监控和重置电路 -
欧时:
Microchip MCP131T-195I/TT 电压监控器, 1.853 至 1.948 V监控电压, 低电平有效, 3引脚 SOT-23B封装
立创商城:
MCP131T-195I/TT
得捷:
IC SUPERVISOR 1 CHANNEL SOT23-3
e络盟:
# MICROCHIP MCP131T-195I/TT 芯片, 电压监控器, 1.95V, 低有效, SOT-23B
艾睿:
In the event that a core processor fails in your circuit, the MCP131T-195I/TT processor from Microchip Technology supervisory ensures that there is a backup to take over. It has a typical reset threshold voltage of 1.9 V, with a minimum of 1.872 V and a maximum of 1.929 V. This device has a minimum operating supply voltage of 1 V and a maximum of 5.5 V. This part has a minimum operating temperature of -40 °C and a maximum of 125 °C.
Allied Electronics:
Microchip MCP131T-195I/TT, Voltage Supervisor 1.853 to 1.948 V, 3-Pin SOT-23B
Chip1Stop:
Volt Supervisor Supply 1.9V 3-Pin SOT-23B T/R
Newark:
# MICROCHIP MCP131T-195I/TT Voltage Supervisor, 1V-5.5V supply, 1.9V Threshold, 120 ms Delay, Active-Low, Open-Drain, SOT-23B-3
DeviceMart:
IC SUPERVISOR 1.95V LOW SOT-23B
电源电压DC 1.00V min
供电电流 1.00 µA
针脚数 3
静态电流 1.00 µA
阈值电压 1.9 V
复位电压Min 1.872 V
复位电压Max 1.929 V
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压Max 5.5 V
电源电压Min 1 V
安装方式 Surface Mount
引脚数 3
封装 SOT-23-3
长度 3.04 mm
宽度 1.4 mm
高度 1.02 mm
封装 SOT-23-3
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Cut Tape CT
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MCP131T-195I/TT Microchip 微芯 | 当前型号 | 当前型号 |
MCP131T-300E/TT 微芯 | 类似代替 | MCP131T-195I/TT和MCP131T-300E/TT的区别 |
MCP131T-270E/TT 微芯 | 类似代替 | MCP131T-195I/TT和MCP131T-270E/TT的区别 |
MCP131T-315E/TT 微芯 | 类似代替 | MCP131T-195I/TT和MCP131T-315E/TT的区别 |
