板机接口压力传感器 UNCOMPENSATED
Overview
MPX53/MPXV53GC series silicon piezoresistive pressure sensors deliver standard, cost-effective, uncompensated sensors that allow you add your own external temperature compensating and signal conditioning networks to designs.
* Offers a low cost solution for medical and industrial applications such as air movement/environmental control systems, level indicators, leak detection, medical instrumentation, industrial/pneumatic controls, and robotics
* Provides a very accurate and linear voltage output, directly proportional to the applied pressure
* Enables simplified compensation techniques because of the predictability of ’s single element strain gauge design
MoreLess
## Features
* Cost-effective
* Patented silicon shear stress strain gauge design
* Ratiometric to supply voltage
* Easy-to-use chip carrier package options
* Differential and gauge options
* 60 mV span typical
## Features
电源电压DC 3.00V min
无卤素状态 Not Halogen Free
输出电压 ≤80.0 mV
供电电流 6.00 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 3 V
电源电压Max 6 V
电源电压Min 3 V
安装方式 Through Hole
引脚数 4
封装 344B-01
封装 344B-01
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tray
制造应用 板式安装
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
