Differential/Gauge Pressure Sensors up to 10 kPa, FreescaleMEMS-based low-pressure differential/gauge sensors measure the difference in pressure between sources when pressure is applied to both sides of the sensor differential and atmospheric pressure gauged.### 压力传感器，Freescale
Differential/Gauge Pressure Sensors up to 10 kPa, Freescale
MEMS-based low-pressure differential/gauge sensors measure the difference in pressure between sources when pressure is applied to both sides of the sensor differential and atmospheric pressure gauged.
### ，Freescale
欧时:
NXP 6kPa 热塑性 计量 模拟 压力传感器 MPVZ4006GW7U, ±2.46 %精确度, 4.6 V输出
得捷:
SENSOR 0.87PSIG 0.22" 4.6V
立创商城:
MPVZ4006GW7U
e络盟:
压力传感器, 计量器, 766 mV/kPa, 0 kPa, 6 kPa, 4.75 V, 5.25 V
艾睿:
Pressure Sensor 0.2V to 4.8V 0kPa to 6kPa Gage 8-Pin Case 1560-02 Tube
安富利:
Pressure Sensor 0.2V to 4.8V 0kPa to 6kPa Gage 8-Pin SOP Rail
Verical:
Pressure Sensor 0.2V to 4.8V 0kPa to 6kPa Gage 8-Pin Case 1560-02 Tube
Newark:
Pressure Sensor, Gauge, 766 mV/kPa, 0 kPa, 6 kPa, 4.75 V, 5.25 V
电源电压DC 4.75V min
无卤素状态 Not Halogen Free
输出电压 0.2V ~ 4.8V
供电电流 10.0 mA
针脚数 8
工作温度Max 60 ℃
工作温度Min 10 ℃
精度 ±5 %
电源电压 4.75V ~ 5.25V
电源电压Max 5.25 V
电源电压Min 4.75 V
安装方式 Through Hole
引脚数 8
封装 DIP-8
封装 DIP-8
工作温度 10℃ ~ 60℃
产品生命周期 Active
包装方式 Each
制造应用 板式安装
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
