Circuit Breaker; Mag; Togl; Cur-Rtg 6A; DINRail; 1Pole; Vol-Rtg 240, 480Y/277VAC; D
**Features:
**
* Small Size — L × W × H, mm: 81 × 18 Per Pole × 75**
**
* DIN Rail Mount**
**
* Two Trip Curves: C — 7-10 Times Rating; D — 10-14 Times Rating**
**
* Positive Indication of Contact Disconnect**
Applications Permitting Supplementary Protectors:
**
* Supplements or Provides Additional Protection for Sensitive Electronics Inside the Equipment**
**
* Used on the Load Side of Branch Circuit Protection to Protect Criteria or Sensitive Internal Circuitry Such as: Computers and Microprocessors, Communications Equipment, Electronic Controllers and Power Supplies**
**
* Permitted for Protection of Motor Control Circuits NEC 430-72, Unless Transformers Are in Circuit, Then UL 489**
Specifications:
**
* Ampere Ratings: From 0.5 to 63 Amps**
**
* 10K Air @ 120/240 VAC; 5K Air @ 480Y/277 VAC**
**
* DC Ratings C-Curve Only: 1-Pole — 60 VDC; 2-Pole — 125 VDC
