MCP1826 低压降电压稳压器
MCP1826 低压降电压稳压器
### LDO(低压降)线性稳压器,
得捷:
IC REG LINEAR 3V 1A SOT223-5
立创商城:
MCP1826T-3002E/DC
欧时:
Microchip MCP1826T-3002E/DC LDO 稳压器, 3 V输出, 1A最大输出, ±2%精确度, 2.3 → 6 V输入, 5+Tab引脚
艾睿:
This LDO MCP1826T-3002E/DC linear regulator from Microchip Technology gives you control over the voltage levels of your circuit. Its typical dropout voltage at current is 0.25@1A V. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 1Min A. The best way to provide power to your application is by using this, which needs a voltage of at least 2.3 V and no higher than 6 V. With a fixed output that has a voltage of 3 V, this is power management at its best. Users like the load regulation of 0.5%Typ and line regulation of 0.05%/VTyp. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 0.4@1A V. Its polarity is positive.
Allied Electronics:
IC, LINEAR REGULATOR; MAX. INPUT, 6V; OUTPUT, 3V; 1000MA; ACCURACY, 0.5%; SOT223-5
安富利:
LDO Regulator Pos 3V 1A 6-Pin5+Tab SOT-223 T/R
TME:
Voltage stabiliser; fixed; 6V; 3V; 1A; SMD; SOT223-5
Newark:
# MICROCHIP MCP1826T-3002E/DC Fixed LDO Voltage Regulator, 2.3V to 6V, 250mV Dropout, 3Vout, 1Aout, SOT-223-5
输出接口数 1
输入电压DC 2.30V min
输出电压 3 V
输出电流 1 A
供电电流 220 μA
静态电流 0.12 mA
输出电容类型 Ceramic
跌落电压 0.25V @1A
输入电压Max 6 V
输入电压Min 2.3 V
输出电压Min 3 V
输出电流Max 1 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±2 %
输入电压 ≤6 V
安装方式 Surface Mount
引脚数 5
封装 SOT-223-6
长度 6.5 mm
宽度 3.5 mm
高度 1.6 mm
封装 SOT-223-6
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MCP1826T-3002E/DC Microchip 微芯 | 当前型号 | 当前型号 |
MCP1826-3002E/DC 微芯 | 功能相似 | MCP1826T-3002E/DC和MCP1826-3002E/DC的区别 |
