MCP1703T-1202E/MB

MCP1703 低压降电压稳压器### LDO（低压降）线性电压调节器，Microchip

MCP1703 低压降电压稳压器

### LDO（低压降）线性稳压器，

欧时:
Microchip MCP1703T-1202E/MB LDO 稳压器, 1.2 V输出, 250mA最大输出, 2.7 → 16 V输入, 3引脚 SOT-89封装

得捷:
IC REG LINEAR 1.2V 200MA SOT89-3

艾睿:
Never worry about components seeing unstable voltages again by implementing this LDO MCP1703T-1202E/MB linear regulator manufactured by Microchip Technology. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 0.25Typ A. Using the part will provide the power your application needs by requiring a voltage only of 2.7 V and not exceeding a voltage of 16 V. With a fixed output that has a voltage of 1.2 V, this is power management at its best. A load regulation of 1%Typ and line regulation of 0.1%/VTyp is necessary for providing a constant voltage level at your output. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive.

Allied Electronics:
MCP1703T-1202E/MB, LDOVoltage Regulator, 250mA, 1.2V, 2.7 to 16Vin, 3-Pin SOT-89

安富利:
LDO Regulator Pos 1.2V 0.25A 4-Pin3+Tab SOT-89 T/R

富昌:
MCP1703系列 250mA 1.2V 低静态电流 LDO稳压器-SOT-89-3

Chip1Stop:
LDO Regulator Pos 1.2V 0.25A 4-Pin3+Tab SOT-89 T/R

Newark:
# MICROCHIP  MCP1703T-1202E/MB  Fixed LDO Voltage Regulator, 2.7V to 16V In, 750mV Dropout, 1.2V/250mA Out, SOT-89-3

DeviceMart:
IC REG LDO 1.2V 50MA SOT89-3
