MCP111 电压监控器
MCP111 电压监控器
### 监控和重置电路 -
得捷:
IC SUPERVISOR 1 CHANNEL SC70-3
立创商城:
MCP111T-270E/LB
欧时:
Microchip MCP111T-270E/LB 电压监控器, 用于微控制器和微处理器功率监控器, 3引脚 SC-70封装
贸泽:
监控电路 Open Drain
艾睿:
This voltage detector MCP111T-270E/LB voltage monitor IC from Microchip Technology makes protecting your circuit from unwanted voltage spikes easy. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. It has a typical reset threshold voltage of 2.63 V, with a minimum of 2.591 V and a maximum of 2.67 V. This voltage supervisor IC has a minimum operating temperature of -40 °C and a maximum of 125 °C. This device has a minimum operating supply voltage of 1 V and a maximum of 5.5 V.
Allied Electronics:
Microchip MCP111T-270E/LB, Voltage Supervisor, 2.564 to 2.696 V, 3-Pin SC-70
安富利:
Volt Supervisor Detect 2.63V 3-Pin SC-70 T/R
Chip1Stop:
Volt Supervisor Detect 2.63V Automotive 3-Pin SC-70 T/R
儒卓力:
**DETECTOR 2,63V 1,75µA SC70 **
Win Source:
Supervisor Open Drain or Open Collector 1 Channel SC-70-3
电源电压DC 1.00V min
输出电流 10 mA
供电电流 1.00 µA
静态电流 1.00 µA
阈值电压 2.63 V
复位电压Min 2.591 V
复位电压Max 2.67 V
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 5.5 V
电源电压Max 5.5 V
电源电压Min 1 V
安装方式 Surface Mount
引脚数 3
封装 SC-70-3
长度 2.25 mm
宽度 1.35 mm
高度 1 mm
封装 SC-70-3
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Automotive
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2014/12/17
ECCN代码 EAR99
