Voltage Detector 4.63V Automotive 3Pin TO-92
Have an extra layer of protection from under and overvoltage conditions in a circuit, keeping all your components safe with this voltage detector voltage monitor IC from Technology. This device has a minimum operating supply voltage of 1 V and a maximum of 5.5 V. This voltage supervisor IC has an operating temperature range of -40 °C to 125 °C. It has a typical reset threshold voltage of 4.63 V, with a minimum of 4.561 V and a maximum of 4.7 V.
电源电压DC 5.50V max
输出电流 10 mA
供电电流 0.00175 mA
静态电流 1.00 µA
阈值电压 4.63 V
复位电压Min 4.561 V
复位电压Max 4.7 V
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压Max 5.5 V
电源电压Min 1 V
安装方式 Through Hole
引脚数 3
封装 TO-92-3
长度 5.21 mm
宽度 3.62 mm
高度 4.62 mm
封装 TO-92-3
工作温度 -40℃ ~ 125℃ TA
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
