ME20A1503B01

ME20A 替代 MENB1020 20 W 15 V Level VI 可互换 墙插式 适配器

A high performance AC to DC external power supply family designed for medical applications. The ME20 Medical Series low power external AC-DC power supplies are approved to safety EN/IEC/UL60601-1, 3rd edition applications with and isolation levels which satisfy the 2 MOPP requirements and designed to UL/EN/IEC60601-1-2, 4th edition for EMC. The ME20 Series models will operate at universal input range of 90 to 264Vac over the wide temperature range of -20°C to +50°C, delivering full rated output power up to +40°C and applicable output power derating at 50°C. These models are available in wall plug and desktop versions, include an IP22 rating per IEC60529 for the enclosure, and the output cable can be terminated at a variety of output connectors.

**Features:**

* Meets UL/EN/IEC60601-1-2, 4th edition for EMC

* Approved to EN/IEC/UL60601-1, 3rd edition applications with and isolation levels which satisfy the 2 MOPP requirements

* Meets DoE Efficiency Level VI Requirements

No load input power

Average Efficiency

* Up to 20W of AC-DC Power

* Universal Input 90-264Vac Input Range

* Desktop Style

* Meets EN55011/CISPR11, FCC Part 15.109 Class B Conducted and Radiated Emissions, with 6db margin

* E-cap life of >10 years

* >1,000,000 hours MTBF

* 3 Year Warranty

* RoHS Compliant
