24VDC 10A 无锁存
* Operating Temperature: –20°C to +80°C
* Contact Rating: 6 A @ 125 VAC, 3 A @ 250 VAC
* Insulation Resistance: 1000 Megohms Min. @ 500 VDC Min. for 1 Minute
* Dielectric Strength: 1500 VAC
得捷:
RELAY GEN PURPOSE 3PDT 10A 24V
立创商城:
24VDC 10A 无锁存
艾睿:
Electromechanical Relay 24VDC 475Ohm 20A 3PDT35.5x35.6x57mm Plug-In General Purpose Relay
Allied Electronics:
RELAY, MULTIMODE, 24 VDC, 3 CO CONTACTS, 11 PIN, W/ LED AND TEST BUTTON
Chip1Stop:
Electromechanical Relay 3PDT 20A 24VDC 475Ohm Socket
Verical:
Electromechanical Relay 24VDC 475Ohm 20A 3PDT 35.5x35.6x57mm Plug-In General Purpose Relay
MASTER:
Power Relay 24VDC 10A 3PDT35.5x35.6x57mm Socket
Electro Sonic:
Power Relay 24VDC 10A 3PDT35.5x35.6x57mm Socket
额定电压AC 400 V
额定电流 10 A
输入电压DC 24.0 V
触点类型 3PDT
跌落电压 2.40 V
触点额定电流 20 A
线圈电压 24 VDC
线圈电流 50.52 mA
线圈功率DC 1.20 W
线圈电阻 475 Ω
额定电流Max 20 A
线圈电压DC 24 V
额定功率Max 2.5 KVA
工作温度Max 60 ℃
工作温度Min -40 ℃
安装方式 Plug In
引脚数 11
封装 -
长度 35.5 mm
宽度 35.6 mm
高度 57 mm
封装 -
触点材质 Silver Nickel
工作温度 -40℃ ~ 60℃
产品生命周期 Active
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
REACH SVHC标准 No SVHC
ECCN代码 EAR99
HTS代码 8536410050
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
MT323024 TE Connectivity 泰科 | 当前型号 | 当前型号 |
8-1393091-4 泰科 | 完全替代 | MT323024和8-1393091-4的区别 |
