RF Power Transistor,470 to 1215MHz, 90W, Typ Gain in dB is 22 @ 860MHz, 50V, LDMOS, SOT1735
Overview
The MRF6VP3091NR1, , MRF6VP3091NR5 and MRF6VP3091NBR5 are designed for broadcast and commercial aerospace broadband applications with frequencies from 470 to 1215 MHz.
MoreLess
## Features
* Capable of Handling 10:1 VSWR, All Phase Angles, @ 50 Vdc, 860 MHz, 90 Watts CW Output Power
* Characterized with Series Equivalent Large-Signal Impedance Parameters
* Internally Input Matched for Ease of Use
* Qualified Up to a Maximum of 50 VDD Operation
* Excellent Thermal Stability
* Device can be used Single-Ended or in a Push-Pull Configuration
* Integrated ESD Protection
* Greater Negative Gate-Source Voltage Range for Improved Class C Operation
* RoHS Compliant
**NOTE: PARTS ARE PUSH–PULL**
## Features
**NOTE: PARTS ARE PUSH–PULL**RF Performance Tables
### 470-860 MHz
Typical Performance UHF 470-860 Reference Circuit: VDD = 50 Volts, IDQ = 450 mA, 64 QAM, Input Signal PAR = 9.5 dB @ 0.01% Probability on CCDF.- .
- *Signal Type** | **Pout
- .
- * | **f
- .
- * | **Gps
- .
- * | **ηD
- .
- * | **Output
Signal PAR
dB- .
- * | **IMD Shoulder
- .
- *
\---|---|---|---|---|---|---
DVB-T 8k OFDM| 18 Avg. | 470| 21.8| 31.0| 7.9| –27.8
650| 21.6| 26.4| 8.4| –37.6
860| 21.7| 27.6| 7.1| –30.4
### 960-1215 MHz
Typical Performance L-band 960-1215 MHz Circuit:
VDD = 50 Volts, IDQ = 100 mA.- .
- *Signal Type** | **Pout
- .
- * | **f
- .
- * | **Pin
- .
- * | **Gps
- .
- * | **ηD
- .
- *
\---|---|---|---|---|---
Pulse 128 µsec,
10% Duty Cycle| 90 Peak | 960| 1.3| 18.4| 55.3
1030| 1.41| 18| 56.9
1090| 1.65| 17.4| 50.7
1215| 1.68| 17.3| 51.0
