ARM MCU微控制单元, Kinetis V Family KV1x Series Microcontrollers, ARM 皮质-M0+, 32位, 75 MHz, 64 KB, 16 KB
Overview
The Kinetis® KV1x MCU family is the entry point of the V series. Built upon the Arm® Cortex®-M0+ core running at 75 MHz with hardware square root and divide capability, it delivers a 27% increase in performance in math-intensive applications versus comparable MCUs, allowing it to target BLDC as well as more computationally demanding PMSM motors. Additional features include integrated FlexCAN, dual 16-bit analog-to-digital controllers ADCs sampling at up to 1.2 mega samples per second MS/s in 12-bit mode, multiple motor control timers, up to 128 KB of flash memory and a comprehensive enablement suite from ® and third-party resources, including reference designs, software libraries and motor configuration tools.
The KV1x family is enabled with Kinetis Motor Suite KMS. KMS is a software solution that enables the rapid configuration of motor drive systems, and accelerates development of the final motor drive application, whilst improving overall motor system performance. KMS simplifies motor control across variable speeds and loads of any type of 3-ph PMSM motor regardless of power level. For more information on Kinetis Motor Suite go to nxp.com/kms
MoreLess
## Features
* 75 MHz Cortex®-M0+ core with hardware square root and divide block— improves performance in math-intensive applications e.g., processing of sensorless field-oriented control FOC algorithms
* 4-channel DMA — reduced CPU loading for improved application performance
* 2x 16-bit ADCs with two capture and hold circuits and up to 1.2 MS/s samples rate in 12-bit mode — simultaneous measurement of current and voltage phase, reduced jitter on input values improving system accuracy 12-bit mode
* Up to 2 x 6-channel and 4 x 2 -channel programmable FlexTimers — High-accuracy PWM generation with integrated power factor correction or speed sensor decoder incremental decoder/hall sensor
* 12-bit DAC and 2 x ACPMs analog comparators— over-current and over-voltage fault detection, reduced BOM costs. ADC and ACMP interconnect with PWM and PDB programmable delay blocks for real-time hardware control
* Dual watchdogs — compliance with IEC 60730 safety regulation requirements
* Broad family scalability with hardware and software compatibility — easy migration to more performance, memory and feature integration within the Kinetis® V series
