Pressure Sensor 0.1V to 3.1V 0kPa to 10kPa Gage Automotive 8Pin Case 1369-01 Tray
0 to 10 kPa 0 to 1.45 psi
0.1 to 3.1 V Output
The MP3V5010 series piezoresistivetransducers are state-of-the-art monolithic silicon pressure sensors designed for a wide range of applications, but particularly those employing a microcontroller or microprocessor with A/D inputs. This transducer combines advanced micromachining techniques, thin-film metallization, and bipolar processing to provide an accurate, high level analog output signal that is proportional to the applied pressure.
Features
• 5.0% Maximum Error Over 0°to 85°C
• Ideally Suited for Microprocessor or Microcontroller-Based Systems
• Temperature Compensated Over –40°to +125°C
• Thermoplastic PPS Surface Mount Package
• Patented Silicon Shear Stress Strain Gauge
• Available in Differential and Gauge Configurations
