MWDM1L-15SCBRPT-.150

Conn Micro D-Subminiature SKT 15POS 2.54mm Solder RA Thru-Hole 15 Terminal 1Port

The micro d-subminiature DVI connector from is ideal for communicating with any serial connections you have. This socket type connector"s 15 contacts that are made out of copper alloy and plated with gold over nickel. Its pitch is 2.54 mm. This 2-row connector has a single port. It has a right angle body orientation. MWDM1L-15SCBRPT-.150 is housed in liquid crystal polymer. This device has a maximum current rating of 3 A. This product is 23.75 mm long, 7.87 mm tall and 15.75 mm deep. This DVI connector has an operating temperature of -55 to 150 °C. Its 15 terminals use the solder termination method.
