Module DC-DC 24Vin 1Out 24V 4.17A 100W 9Pin Half-Brick
隔离模块 直流转换器 输出 24V - - - 4.17A 18V - 36V 输入
得捷:
DC DC CONVERTER 24V 100W
贸泽:
Isolated DC/DC Converters 100W 24Vin 24Vout 20A Half-Brick
Allied Electronics:
Power Supply; DC-DC; 100W DC-DC Regulated, 1/2Brick100W; IP:18-36V; OP:24V4.17A
Jameco:
100 Watt DC-DC Half-Brick Regulated Single Output Converter24 Volts @ 4.17 Amps 24V
TME:
Converter: DC/DC; 100W; Uin:18÷36V; 24VDC; Iout:4.17A; 95g; 500kHz
MASTER:
Module DC-DC 24VIN 1-OUT 24V 4.17A 100W 9-Pin Half-Brick
Electro Sonic:
Module DC-DC 24VIN 1-OUT 24V 4.17A 100W 9-Pin Half-Brick
CDI:
DC/DC 100W 24V Half Brick Regulated Converter
Win Source:
DC DC CONVERTER 24V 100W / Isolated Module DC DC Converter 1 Output 24V 4.17A 18V - 36V Input
额定功率 100 W
输出接口数 1
输入电压DC 18V ~ 36V
输出电压 24 VDC
输出电流 4.17 A
输出功率 100 W
开关频率 500 kHz
输出功率Max 100 W
输入电压 18VDC ~ 36VDC
安装方式 Through Hole
封装 1/2 Brick
长度 57.912 mm
宽度 60.96 mm
高度 12.7 mm
封装 1/2 Brick
重量 95 g
工作温度 -40℃ ~ 100℃
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8542390000
